Hybrid Quantum-Classical Computing: Examples for Optimization (Updated)

What Changed Since the Previous Version

1. Introduction

Hybrid quantum-classical computing combines the strengths of classical and quantum systems to solve complex optimization problems. While quantum computers excel at exploring large solution spaces, classical computers handle preprocessing, postprocessing, and control logic.

In this article, you’ll learn how to build hybrid optimization workflows in Java with the Strange library, focusing on implementing the Quantum Approximate Optimization Algorithm (QAOA).

2. Key Concepts

2.1 What is Hybrid Quantum-Classical Computing?

• Classical Computing: Handles data processing, control logic, and refinement.
• Quantum Computing: Solves specific tasks like optimization using quantum algorithms.
• Synergy: Combines both to tackle problems more efficiently.

2.2 Applications in Optimization

• Traveling Salesman Problem (TSP)
• Portfolio Optimization
• Supply Chain Optimization
• Machine Learning Hyperparameter Tuning

3. Tools for Hybrid Quantum-Classical Computing in Java

1. Strange

• Java library for simulating quantum circuits.
• Provides qubits, gates, and a local execution environment.
• Does not currently include a built-in QAOA API — you construct circuits manually.

2. JQuantum

• Another Java-based simulator.
• Less active, but educational for learning the basics.

4. Implementing Hybrid Optimization with Strange

QAOA requires:

• A classical optimizer to tune variational parameters (γ, β).
• A cost Hamiltonian encoding the optimization problem.
• A mixer Hamiltonian (typically RX rotations).

Step 1: Add Dependencies

<dependency>
    <groupId>org.redfx</groupId>
    <artifactId>strange</artifactId>
    <version>0.1.3</version>
</dependency>
<dependency>
    <groupId>org.apache.commons</groupId>
    <artifactId>commons-math3</artifactId>
    <version>3.6.1</version>
</dependency>

• strange → quantum circuit simulator.
• commons-math3 → classical optimization routines.

Step 2: QAOA Example in Java

Below is a simplified Max-Cut example using QAOA with depth p = 1.

import org.redfx.strange.Program;
import org.redfx.strange.Step;
import org.redfx.strange.gate.Hadamard;
import org.redfx.strange.gate.Cnot;
import org.redfx.strange.gate.RX;
import org.redfx.strange.gate.RZ;
import org.redfx.strange.local.SimpleQuantumExecutionEnvironment;
import org.redfx.strange.QuantumExecutionEnvironment;
import org.redfx.strange.Result;

import org.apache.commons.math3.optim.nonlinear.scalar.noderiv.NelderMeadSimplex;
import org.apache.commons.math3.optim.nonlinear.scalar.noderiv.SimplexOptimizer;
import org.apache.commons.math3.optim.MaxEval;
import org.apache.commons.math3.optim.InitialGuess;
import org.apache.commons.math3.optim.PointValuePair;
import org.apache.commons.math3.optim.nonlinear.scalar.GoalType;

public class HybridQAOAExample {

    // Example Hamiltonian: Max-Cut on a 2-node graph with one edge
    private static double[][] hamiltonian = {
        {0, 1},
        {1, 0}
    };

    public static void main(String[] args) {
        int p = 1; // QAOA depth
        double[] initialParams = {0.5, 0.5}; // gamma, beta

        SimplexOptimizer optimizer = new SimplexOptimizer(1e-6, 1e-6);
        NelderMeadSimplex simplex = new NelderMeadSimplex(initialParams.length);

        PointValuePair result = optimizer.optimize(
            new MaxEval(200),
            org.apache.commons.math3.optim.nonlinear.scalar.ObjectiveFunction.wrap(params -> {
                return -evaluateQAOA(params, p); // optimizer minimizes
            }),
            GoalType.MINIMIZE,
            new InitialGuess(initialParams),
            simplex
        );

        double[] best = result.getPoint();
        System.out.println("Best params: ?=" + best[0] + ", β=" + best[1]);
        System.out.println("Optimal value: " + (-result.getValue()));
    }

    private static double evaluateQAOA(double[] params, int p) {
        double gamma = params[0];
        double beta = params[1];

        Program program = new Program(2);

        // Initial superposition
        Step init = new Step();
        init.addGate(new Hadamard(0));
        init.addGate(new Hadamard(1));
        program.addStep(init);

        // Cost unitary (ZZ interaction)
        Step cost = new Step();
        cost.addGate(new Cnot(0, 1));
        cost.addGate(new RZ(gamma, 1));
        cost.addGate(new Cnot(0, 1));
        program.addStep(cost);

        // Mixer unitary
        Step mix = new Step();
        mix.addGate(new RX(2 * beta, 0));
        mix.addGate(new RX(2 * beta, 1));
        program.addStep(mix);

        QuantumExecutionEnvironment env = new SimpleQuantumExecutionEnvironment();
        Result r = env.runProgram(program);

        // Compute expected cost from measurement outcomes
        double expectedValue = 0.0;
        for (int i = 0; i < r.getProbability().length; i++) {
            double prob = r.getProbability(i);
            int[] bits = decodeBits(i, 2); // helper to decode basis state
            expectedValue += costFunction(bits) * prob;
        }
        return expectedValue;
    }

    // Max-Cut cost function
    private static double costFunction(int[] bits) {
        return (bits[0] ^ bits[1]) == 1 ? 1.0 : 0.0;
    }

    // Convert integer index to bitstring
    private static int[] decodeBits(int index, int n) {
        int[] bits = new int[n];
        for (int i = 0; i < n; i++) {
            bits[i] = (index >> i) & 1;
        }
        return bits;
    }
}

5. Classical Preprocessing & Postprocessing

In a hybrid workflow:

• Preprocessing: Translate your problem into a Hamiltonian (e.g., adjacency matrix for Max-Cut).
• Quantum Computation: Build parameterized circuits and simulate them.
• Postprocessing: Extract solutions, refine them, and possibly combine with local search.

Example preprocessing helper:

private static double[][] generateHamiltonian() {
    return new double[][] {
        {0, 1, 1, 0},
        {1, 0, 0, 1},
        {1, 0, 0, 1},
        {0, 1, 1, 0}
    };
}

6. Conclusion

Hybrid quantum-classical computing is a powerful way to tackle optimization problems. While Java libraries like Strange don’t yet provide high-level algorithm APIs such as QAOAProblem, you can still implement QAOA circuits manually and pair them with classical optimizers.

This not only gives you flexibility but also helps you understand the mechanics of hybrid algorithms. As the Java quantum ecosystem grows, more complete abstractions may emerge.

For now, building QAOA by hand in Strange provides a hands-on path to experiment with hybrid computing in logistics, finance, and machine learning.

Happy coding!
